Interfaces
Gigabit RJ45 Ports 8
Speed/Link/Act of Each Ethernet Port
Performance Copper Speed and Distance
Cat. 3 or higher cable: 100 meters at 10 Mbps
Cat. 5 or higher cable: 100 meters at 100 Mbps
Cat. 5e or higher cable: 170 meters at Gigabit
Max Switching Capacity
16 Gbps
Max Forwarding Rate
11.904 Mpps
Power
Basic Power Saving True
Power Adapter in the Box
Input: 100-240V~, 50/60Hz
Max Power Consumption
2.75W
Power Consumption
Idle 2.2W
Switching Protocols
802.3
Reliability EMS
IEC/EN 61000-4-2, Level 2 ESD: Contact: 4kV; Air: 8kV
Level 3 Surge
2kV: IEC/EN 61000-4-5
Environment
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature:
-40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity:
10% ~ 90% non-condensing
Storage Humidity:
5% ~ 90% non-condensing
Mechanical Dimension
138×78×25 mm
Product Weight
211 g (7.44 oz.)
