Interface
16× 10/100/1000Mbps RJ45 Ports
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
External Power Supply
External Power Adapter (Output: 53.5 VDC / 2.43 A)
Packet Forwarding Rate
23.8 Mpps
PoE Ports (RJ45)
Standard: 802.3 af/at compliant
8K, Auto-learning, Auto-aging
Switching Capacity
32 Gbps
Dimensions
286 × 111.7 × 25.4 mm
Max Power Consumption
11.72 W (220 V / 50 Hz no PD connected) /
11.56 W (110 V / 60 Hz no PD connected)
142.51 W (220 V / 50 Hz with 120 W* PD connected) /
144.28 W (110 V / 60 Hz with 120 W* PD connected)
Max Heat Dissipation
39.85 BTU/h (220 V / 50 Hz no PD connected) /39.31 BTU/h (110 V / 60 Hz no PD connected)
484.53 BTU/h (220 V / 50 Hz with 120 W* PD connected) /490.55 BTU/h (110 V / 60 Hz with 120 W* PD connected)
Advanced Features
Compatible With IEEE 802.3af/at Compliant PDs
Extend Mode Button (Ports 1–4, Up to 250 m PoE power supply and data transmission)
Priority Mode Button (Ports 1–4)
Isolation Mode Button (Ports 1–7 / 8-14)
PoE Auto Recovery (Ports 1-16)
Mac Address Auto-Learning And Auto-Aging
Transfer Method
Store-And-Forward
Certification
FCC, CE, RoHS
Environment
Operating Temperature: 0–40 ℃ (32–104 ℉);
Storage Temperature: -40–70 ℃ (-40–158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing
